| MPPT Solar Charge Controller |
 |
- Multifunctional protection
- Pure sine wave output, full power
- 100% uninterrupted power
- Built-in MPPT solar controller 30A-100A (optional)
- With UPS automatic switching function, mains charging function, AVR voltage stabilization function (three-stage voltage stabilization)
- Specific overload, high voltage, low voltage, short circuit and other perfect protection functions
- DSP intelligent chip control, excellent performance
- Strong inverter capacity, one-time soft start, triple output peak power, can carry all inductive loads
- Fully personalized LCD display, at the same time display solar controller, inverter related information
- Mains power priority, energy saving mode, solar power priority can be set freely to meet different occasions
- Battery type, charging voltage, mains charging current (0-35A) can be set freely to meet different types
- Battery charge management
|
| Default battery system voltage (VDC) |
12VDC/24VDC/48VDC |
|
| Inverter Output |
Rated power |
3000W |
| Surge rating (20ms) |
9000W |
| Capable of starting electric Motor |
2HP |
| Wave form |
Pure sine wave/ Same as input (AC mode) |
| Nominal output voltage RMS |
110/120VAC 220/230/240VAC(±10RMS) |
| Output frequency |
50Hz60Hz±0.3Hz |
| Inverter efficiency(Peak) |
>85% |
| Line mode efficiency |
>95% |
| Typical transfer time |
8ms(Max) |
| Solar Charge Controller |
Max solar charging current |
30A,40A,50A,60A,80A |
| Voltage |
12V,24V,48V,96V |
| Max PV input power |
12V-30A:360W,12V-50A:600W,12V-60A:720W,12V-80A:960W,12V-100A:1200W,12V-120A:1440W |
| 24V-30A:720W,24V-50A:1200W,24V-60A:1440W,24V-80A:1920W,24V-100A:2400W,24V-120A:2880W |
| 48V-30A:1440W,48V-50A:2400W,48V-60A:2880W,48V-80A3840W,48V-100A:4800W,48V-120A:5760W |
| 96V-80A:7680W,96V-100A:9600W,96V-120A:11520W |
| PV array MPPT voltage range |
12V:18V-100V,24V:36V-130V,48V:72V-160V,96V:144V-280V |
| Peak conversion efficiency |
>99% |
| Other |
Mounting |
Wall mount |
| Display |
LCD+LED |
| Cooling fan |
Intelligent fan cooling system |
| Audible noise |
<60dB |
| Coommunications |
RS-232,SNMP,WI-FI,Dry Contact(Optional） |
| Operation temperature range |
-10℃~50℃ |
| Storage temperature |
-10℃~60℃ |
| Protection |
Over load protection |
Rated power over 110%,shut down automatically |
| Temperature protection |
Built-in temperature sensor real-time induction, ,≥85 alarm, ,≥85 shut down the whole machine |
| Short circuit protection |
Automatic Shutdown |
| Battery |
Low battery protection |
10VDC±0.3V (12VDC),20VDC±0.3V (24VDC),40 VDC±0.3V (48VDC),80 VDC±0.3V (96VDC) |
| Low battery cutoff |
10.5VDC±0.3V (12VDC),21VDC±0.3V (24VDC),42 VDC±0.3V (48VDC),84VDC±0.3V (96VDC) |
| High Battery alarm |
15VDC±0.3V (12VDC),30VDC±0.3V (24VDC),60 VDC±0.3V (48VDC),120 VDC±0.3V (96VDC) |
| High Battery protection |
16.5VDC±0.3V (12VDC),33VDC±0.3V (24VDC),66VDC±0.3V (48VDC),132VDC±0.3V (96VDC) |
