| Model |
MDSH900S |
| Compressor |
Free air delivery |
m3/min |
25.2 |
| cu.ft/min |
900 |
| Discharged pressure |
bar |
17 |
| psig |
246.5 |
| Safety valve setting |
bar |
19 |
| Capacity |
250L |
| Total amount of lubricant |
L |
135 |
| Maximum oil temperature |
℃ |
105 |
| Diesel Engine |
Model |
YC6MK400L-K20 |
| Cylinders |
6 |
| Displacement (L) |
10,338 |
| Rotating speed |
Working speed (rpm) |
2000 |
| Idle speed(rpm) |
1300 |
| Rated power KW[HP] |
295 |
| Lubricating oil capacity/（L） |
28 |
| Fuel tank capacity/（L） |
495L（900S) |
| Coolant capacity |
L |
40 |
| Battery voltage |
24 |
| Applicable altitude |
≤2500m |
| Weight |
KG |
5630 |
If you want to know more about the protable screw air compressor,please contact us!
